Shell Water-Glycol S2 CX

A smokey liquid metal factory being inspected by workers

Lubricants

Reducing the risk of fire hazards

Minimise the risk of fire in high-pressure hydraulic systems with Shell Water-glycol S2 CX, a fire-resistant fluid that provides high protection against corrosion and pump wear – and is specifically designed to operate at system pressures up to 4,000 psi.

Industrial operations that require high-pressure hydraulic systems and extreme temperatures face an increased risk of fire – creating additional potential hazards for the people running them.

So, it is vital that equipment used for applications such as die casting, welding and hot metal pressing uses hydraulic fluids that can handle the pressure.

Performance Advantages

Worker at a furnace pouring melted metal

Deliver peak performance

Using fire-resistant lubricants is a cost-effective option compared with installing mechanical fire-suppression equipment. With a 42–44% water content, Shell Water-Glycol S2 CX is an HFC type, fire-resistant hydraulic fluid designed for use in industrial equipment operating in areas subject to fire hazards, including in the steel, aluminium, die-casting, mining, glass and tunnel boring industries. It has a higher ignition temperature and lower flammability than mineral oils, and its glycol (diethylene glycol) content enables the fluid to be used in all seasons.

The fluid uses an innovative friction modifier to provide excellent pump lubricity, which can help to extend equipment service life and reduce maintenance costs. In the Vickers V-104 vane pump test, only 10–15 mg of wear was recorded after 100 hours at 2,000 psi and 65°C (ASTM D7043).

As an FM Approved Fire-Resistant industrial fluid, Shell Water-Glycol S2 CX

  • Featuring a high level of anti-wear protection, Shell Water-Glycol S2 CX is engineered to offer increased resistance to mechanical shear and has a stable viscosity that helps to protect components against wear.
  • Provides corrosion protection to a wide variety of metals, including aluminium, copper, brass, cast iron, steel and others commonly used in hydraulic systems.
  • Water based hydraulic systems have been traditionally used in underground mining applications and in the high temperature areas of steel mills and foundries

Environmental Advantages

Old mine in coastal setting

Protect your equipment and the environment

As the name implies, water-glycol fluids consist of a solution of water, ethylene or diethylene glycol, a thickener and an additive package. The additive system contains anti-wear protection, as well as corrosion resistance, metal passivation, oxidation resistance, antimicrobial properties, seal in hose compatibility, and a pink or red dye to aid in identification.

The development of water-glycol hydraulic fluids has been driven by a multitude of changes impacting industry. For example, environmental concerns have pushed the industry to look for fluids that are biodegradable1, less harmful to the environment and more easily cleaned up.

  • Lower clean-up costs: Water-based hydraulic systems hold the potential for tremendous cost savings at the plant level due to lower associated clean-up costs.
  • Safety: The inherent fire resistance of the fluid increases safety.
  • Wear protection: The incorporated additive packages reduce wear and tear on equipment, helping to maximise the life of equipment.

Service Life Advantages

Liquid metal furnace using water

Lower operating costs and reducing downtime

Shell Water-Glycol S2 CX helps to minimise fluid maintenance, extend pump life and reduce reconditioning requirements. It does this through its high shear stability, along with its superior vapour phase and solution corrosion protection, compared with traditional water-glycol fluids.

The fluid uses an innovative friction modifier to provide excellent pump lubricity, which can help to extend equipment service life and reduce maintenance costs. In the Vickers V-104 vane pump test, only 10–15 mg of wear was recorded after 100 hours at 2,000 psi and 65ºC (ASTM D7043).

  • Lower clean-up costs: Water-based hydraulic systems hold the potential for tremendous cost savings at the plant level due to lower associated clean-up costs.
  • Rust and corrosion protection: Water-glycol fluid formulations incorporate additives that reduce rust and corrosion in systems, further helping to extend service life of both the equipment and fluid itself.
  • Predictable service life: Water-glycol fluid formulations can be tested and monitored to measure fluid life, giving operators insight as to when replacement may be needed.

Excellent fire-resistance coupled with good cost and performance makes water-glycol fluids a good choice for many industrial applications.

Shell Water-Glycol S2 CX specifications

Method Shell Water-Glycol S2 CX 46
ISO fluid type ISO 67 43-4 HFC
Colour Visual Red
Kinematic viscosity at 40°C, mm 2/5 ISO 3104 46
Viscosity index  ISO 2909 196
Density at 15°C, kg/m³ ISO 12195 1080
pH 9.5
Water content, % ASTM E203 42 – 44
Pour point ISO 3016 -50
Four-ball wear test, mm ISO 20623 0.60
These characteristics are typical of current production. Although future production will conform to Shell’s specifications, variations in these characteristics may occur.

Download the product sheet

Learn more about how Shell Water-Glycol S2 CX can improve the productivity and safety of your operations while extending the service life of your hydraulic systems.

Discover more

The many benefits of Shell water-glycol fire-resistant hydraulic fluids

Read our white paper to explore the benefits of Shell water-glycol fire-resistant hydraulic fluids and why they are important to your business.

Discover more
