Shell LNG can help reduce the “well-to-wheel” greenhouse gas emissions from heavy-duty trucks by up to 22% compared to conventional diesel today, with further reductions possible in the future.2
Discover how switching your fleet from conventional diesel trucks to liquified natural gas (LNG) trucks that run on LNG or BioLNG can help your road freight business reduce emissions today, without risking overall performance.
The road freight industry accounts for approximately 9% of global carbon dioxide emissions, so rapid change is essential. However, the issue is complex and requires a mosaic of solutions. Cleaner-burning fuels like LNG and BioLNG offer a stepping stone on the path to zero-emissions fleets.
See how we turn natural gas into a liquid for easier transport overseas
Duration: 2:48 minutes
The methodology and benefits of the liquefaction of natural gas for transportation in order to meet the global energy demand.
What is LNG - Turning natural gas into liquid - from YouTube Transcript
[Background music plays]
Rhythmic instrumental music plays.
Aerial view of animated grey gridlines on a white background.
Pull back to wide view of 3D simulation of a city skyline rising out of the gridlined background.
Pan and pull back to aerial view of the skyline, which levels out to two 3D yellow blocks, labelled Population and Demand, still surrounded by a white background with grey gridlines, the blocks casting a shadow in front of them.
Pull back to wide front view of the blocks as four more appear frame-right of the first two. The blocks are labelled 2000, 2010, 2020, 2030, 2040 and 2050, and rise incrementally in height from left to right. The blocks cast a slight grey shadow just in front of them against a white background.
The world’s population is growing and, for many, living standards will continue to improve. As a result, global energy demand is expected to double by 2050 when compared to 2000.
Population / Demand
To help meet this demand, gas will form an increasingly important role.
2000 / 2010 / 2020 / 2030 / 2040 / 2050
Zoom to the blocks as they decrease and disappear into the white, gridlined background.
Natural gas is plentiful, and it’s the cleanest-burning fossil fuel.
Aerial view of gridlined surface as a simulation of a rotating globe of the earth emerges from the surface, continents visible in a mustard colour and the oceans between in pale blue, the globe casting a faint grey shadow in a south-easterly direction.
But some natural gas resources are in remote locations: transporting the gas long distances by pipeline can be costly and impractical. The solution?
The simulation of the globe morphs into a teardrop of blue liquid against the white, gridlined background. The drop of liquid rolls downwards and disappears.
We liquefy the gas by cooling it, which shrinks its volume for easier, economical and safe transportation by ship.
Zoom in on a vertical cylindrical shape, a simulated pipeline, as it emerges out of the white, gridlined background.
Simulated gas particles of many colours float upwards through the pipe, and shadows appear either side of the pipe to simulate the reflection of the pipeline running along the ground’s surface.
Pan down to oblique, horizontal angle of the pipeline as coloured particles flow frame left to frame right, all still against the white background with grey gridlines and shadows.
Pull back to an aerial view of a network of pipes along which particles are flowing, all stemming from one pipe, similar to the shape of a fork, but with many tines.
So, how is liquefied natural gas produced? Natural gas extracted from the ground contains impurities, water and other associated liquids. First it is processed to clean it. It goes through a series of pipes and vessels where gravity helps separate the gas from some of the heavier liquids.
Pull back and pan to an aerial view of the whole plant, one of the large towers displaying the Shell logo.
Zoom to another section of the plant, showing a single pipeline, through which multi-coloured particles are flowing into a tank.
Zoom to close-up of particles, showing the yellow particles, representing carbon dioxide and hydrogen sulphide, being absorbed into the background, disappearing, leaving green, blue, turquoise and purple particles flowing from frame-left to frame-right.
Blue particles, representing water, next veer towards a faint, grey circular opening in the background, disappearing from the simulated flow of particles.
Turquoise particles, representing mainly propane and butane, also veer towards yet another circular opening in the background, leaving many green and some purple particles, representing methane and ethane respectively.
Pull back to rear view of green and purple particles flowing away and disappearing to the top of frame as a bright white section slowly opens up at the top of the pipeline, still indicated by the white gridlined background.
Other impurities are then stripped out. The natural gas passes through a water-based solvent that absorbs carbon dioxide and hydrogen sulphide. These would otherwise freeze when the gas is cooled and so cause blockages. Next any remaining water is removed, as this would also freeze. Finally, remaining lighter natural gas liquids – mainly propane and butane – are extracted to be sold separately or used as a refrigerant later in the cooling process. Traces of mercury are also filtered out. Now the purified natural gas – methane with some ethane – is ready to be liquefied.
Zoom to aerial view of a stylised line animation of three heat exchangers, with pipes flowing along the white gridlined background.
Zoom to central exchanger, the coolant, and pan to front view of the coolant’s yellow-rimmed window, showing cold air blasting downwards over a network of pipes.
Zoom to a close-up of the moving particles against the white-grey gridlined background as they decrease in size and cluster together to fill the screen.
Dissolve to aerial view of a beaker containing water, casting a shadow on the white surface, and panning to a front view of the beaker.
This happens in heat exchangers. A coolant, chilled by giant refrigerators, absorbs the heat from the natural gas. It cools the gas to -162°C, shrinking its volume by 600 times. This turns it into a clear, colourless, non-toxic liquid - liquefied natural gas, or LNG – that is much easier to store and transport.
Tanks and structures rise from the white-grey surface and the beaker becomes opaque and, as we pan to a front view, it turns into an insulated tank, displaying the Shell logo on its front. Pipes running from the tanks towards the foreground appear to flow with blue liquid, the remainder of the background still in whites and greys.
Pull back to aerial view of the plant in the background with an LNG vessel in the foreground, parts of its superstructure coloured in yellow.
The plant structures sink back into the white background as the shot pans down and back behind the stern of the ship. The ship moves rapidly across and out of the frame diagonally from frame-right to frame left.
The LNG is kept in insulated tanks until it is ready for loading into a specially designed LNG ship or carrier.
Quick pan to aerial view of the LNG vessel connected via pipeline to three tanks, blue liquid flowing from the vessel to the tanks.
Pan 180 degrees to three pipelines flowing out of the three tanks, the substance – now denoted by yellow- flowing rapidly along the pipelines which extend to the city skyline, again against the white and grey gridlined background.
Pull back to aerial view of the city and zoom out.
When the ship arrives at its destination, the LNG is transferred to a regasification plant where it is heated, returning it to its gaseous state. The gas is then transported via pipelines to customers, providing energy for homes and industry.
White flash dissolve to Shell logo.
Shell continues to help meet growing energy demand with cleaner burning natural gas.
Many of the towns and cities that need the most energy are located far from gas fields, making pipelines too impractical or costly to build. A solution? Gas can be cooled to make a liquid, shrinking its volume for easier, safer storage - and making it easier to transport overseas too.
BioLNG is gas collected from landfill sites, food waste or manure, then processed until it is fully interchangeable with conventional natural gas. That is why BioLNG makes it possible to significantly reduce CO2 emissions when used neat. It can be blended with liquified natural gas (LNG) to offer additional emission reductions.
Improve competitiveness, meet regulations, and champion lower-emissions fuels with e-mobility.
Hydrogen has the potential to be an important, almost emissions-free, low-carbon transport fuel - particularly for heavy-duty transport such as trucks and buses. In hydrogen vehicles, energy is stored as compressed hydrogen fuel, so you can drive up to 700 km without refuelling. They take just minutes to refuel.
1 A truck running on an LNG gas engine will produce noise levels at 72dB(A), equal to a normal car. An average diesel-powered truck will produce 82 dB(A). To give in idea of how significant that reduction is: every 3dB(A) reduction in noise halves the intensity of the sound (because sound is scientifically measured on a logarithmic scale).
2 “Well-to-wheel” greenhouse gas emission reductions are based on current ISO 9001 standards for analysis and EPA & GREET emissions values. “Greenhouse gas emissions” includes CO2, methane, and N2O.
Help your fleet reduce its carbon footprint - and navigate the net-zero pathway that is ideal for you. Avoid, reduce and offset emissions with a strategy - tailored for your needs - with products and services that will allow you to achieve sustainability, both efficiently and profitably.
The ultimate convenience for all aspects of fleet management. We’re on a mission to make road freight management as frictionless as possible - with easier methods to pay for fuel, simpler ways to plan routes and a new range of services on the road.
Keep costs down with competitive pricing, credit terms and volume-based incentives. We're introducing a new range of solutions to help you avoid emissions, before reducing and compensating for them. So, you’ll be able to reduce your costs while efficiently achieving your decarbonisation goals.
