Tertiary N₂O Abatement
Shell Catalysts & Technologies offers an innovative, energy-efficient tertiary solution for N2O decomposition based on our unique lateral flow reactor (LFR) technology to combat environmental threats and enable industrial plants to both meet clean air regulations and participate in carbon credit programs.
Reducing N2O While Innovating Profitably
With an environmental impact 310 times higher per unit than CO2, nitrous oxide (N2O) has been identified as a significant greenhouse gas (GHG) under the Kyoto Protocol. Shell Catalysts & Technologies’ solution destroys N2O, converting it into naturally occurring nitrogen (N2) and oxygen (O2). It is well suited to reducing N2O emissions from the tail gas streams of industrial and chemical process plants such as nitric acid, Caprolactam, and adipic acid plants – all significant emitters of N2O.
C-NAT has been tested under a wide range of conditions and when properly maintained and operated, it is capable of achieving N2O reductions of more than 98%. C-NAT is a direct N2O decomposition process that does not require the addition of any reducing agent or other reactants. N2O destruction of 98% or higher can be achieved over a range of temperatures and pressures, and no undesirable by-products are formed.
C-NAT can be installed in either the high-pressure position upstream of the expander or in the low-pressure position downstream of the expander. Both options benefit from low-pressure drop by utilising the LFR. Certain processes for the manufacture of caprolactam can have high N2O emissions.
The Shell Catalysts & Technologies’ N2O decomposition catalyst is stable in the presence of small quantities of sulphur oxide (SOx) sometimes present in caprolactam process tail gas. N2O reduction projects can be used to generate tradable carbon credits and financial revenues.
Our innovative solutions can help you meet environmental regulations.
Robust yet cost-effective, the Shell Catalysts & Technologies’ N2O Abatement Technology is a dependable system and far more cost-effective than other technologies available on the market for high N2O reduction
Exceptional performance benefits can be gained by employing a highly active catalyst on tail gas emissions, offering significant N2O re-ductions while having only a low impact on plant operations.
The selective catalytic reduction of nitrogen oxides is cost-effective with Shell Catalysts & Technologies’ DeNOX system (SDS).
High-performance catalysts to remove trace contaminants from carbon dioxide streams prior to further use in chemical, agricultural and/or food applications.
Talk to an Expert
Shell Catalysts & Technologies is dedicated to delivering catalyst products and licensing solutions that provide value to your entire enterprise.
